Description
Parameters and specifications:
Type: Analog input module
Series: GE Fanuc Versamax series
Number of channels: 8 single-ended channels in a group
Voltage range: -10 to +10 volts DC, 0-10 volts DC
Current range: 4-20 mA
Update rate: 0.4 ms
Input filter response: 5.0 ms
Power consumption: 130 mA from the +5V bus
Resolution: 16 bits
Features:
Isolated inputs: With eight isolated inputs, input signals from up to eight independent analog devices can be accepted.
Software configurable: Includes per-channel selection for 4-20mA current or +/-10 V voltage inputs, optional input filters, and pre-channel selection for default and below/over range levels.
Diagnostics: Underrange and overrange, open, outage, non-volatile memory failures, and high or low alarm diagnostics.
LED indicator: Standard, including “INT PWR” LED and “OK” LED to indicate status.
High accuracy: A positive current is applied to the current input, and the two negative terminals of the channel are connected for maximum accuracy.
Functions:
IC200ALG260E is an analog input module mainly used in industrial automation systems to receive signals from current and voltage powered input devices and convert them into digital signals for PLC or other control systems.
