Honeywell TK-PRS021

Description

The Honeywell TK-PRS021 is a process control module designed for monitoring and controlling parameters and variables in industrial production processes. Here is a breakdown of its key parameters, specifications, dimensions, weight, series, features, and applications in English:

Parameters and Specifications:

• Voltage: The TK-PRS021 operates on a 24V DC power supply¹.
• Current: The current range of the module is between 100-400A¹.
• Communication: It supports various communication methods, including RS232, RS422, RS485 serial communication, and Ethernet communication (wired and wireless)².

Dimensions and Weight:

• Dimensions: The exact dimensions of the TK-PRS021 are not provided in the recent search results, but it is mentioned as TK-PRS021mm³. It’s advisable to consult the manufacturer’s official documentation for precise measurements.
• Weight: The weight of the module is approximately 2KG¹².

Series:

• The TK-PRS021 belongs to the PKS series of modules from Honeywell⁴.

Features:

• PWM Pulse Formation: The TK-PRS021 utilizes the SG3525A as the primary technology for PWM (Pulse Width Modulation) pulse formation. It can output pulse frequencies ranging from 20KHZ to 60KHZ, with pulse intervals of 180 degrees and adjustable dead time²⁵⁶.
• IGBT Drive: This control board is suitable for IGBT full-bridge inverter series resonant induction heating device frequency modulation and power adjustment. It has a power range of 10KW to 120KW and features a full-bridge inverter IGBT drive circuit, allowing direct assembly into IGBT high-frequency induction heating equipment²⁵⁶.
• Protection: The TK-PRS021 incorporates various protection features, including over-current, over-voltage, and water shortage protection. It also provides switch-type Hall protection interfaces and linear Hall protection interfaces to ensure stable operation in complex environments²⁵.
• Power Supply: The control board requires a three-way alternating current dual 18V/1A and four 22V/0.5A power supplies for its operation²⁵.

Applications:

• The TK-PRS021 is primarily used in industrial production processes for monitoring and controlling various parameters and variables. Its multifunctional capabilities, including data acquisition, processing, communication, and control, enable precise control of production processes⁴. It can be integrated into automation systems to enhance the efficiency, reliability, and safety of industrial operations.
