Honeywell TK-PRS021 is an IGBT series high-frequency drive board that is primarily used in industrial control applications. Here is a breakdown of its parameters, specifications, dimensions, weight, series, features, and functions in English:
Parameters and Specifications:
Brand: Honeywell
Model: TK-PRS021
Function: IGBT high-frequency drive board
Control Method: PWM pulse formation using the SG3525A chip
Output Pulse Frequency Range: 20KHZ – 60KHZ
Power Range: 10KW – 120KW
Voltage: 24V
Current: 100-400A
Weight: 2KG
Series:
The TK-PRS021 belongs to the Honeywell’s DCS controller series, specifically designed for IGBT high-frequency induction heating applications.
Features:
High-Frequency Drive: The board provides high-frequency drive signals to the IGBT, enabling efficient and precise control of inductive heating processes.
PWM Pulse Formation: Using the SG3525A chip, the board generates PWM pulses with a frequency range of 20KHZ – 60KHZ, providing precise control over the power output.
Versatile Control: The board is suitable for a wide range of power outputs, from 10KW to 120KW, making it suitable for various industrial applications.
Multiple Protections: Features such as over-current, over-voltage, and water-cooling protection ensure the reliability and safety of the system.
Modular Design: The board is designed with a modular structure, facilitating easy integration and replacement of components.
Functions:
IGBT Drive: The TK-PRS021 provides the necessary drive signals to the IGBT, enabling it to function efficiently in inductive heating applications.
Power Control: By adjusting the PWM pulse frequency and duty cycle, the board controls the power output of the inductive heating system.
Protection Functions: The board incorporates various protection features to safeguard the system from potential faults and damage, such as over-current, over-voltage, and water-cooling issues.
Dimensions and Weight:
The dimensions of the TK-PRS021 board are TK-PRS021mm, and its weight is 2KG.
Applications:
The Honeywell TK-PRS021 is primarily used in IGBT high-frequency induction heating applications, such as metal heating, welding, and brazing.
Please note that for detailed specifications, dimensions, weight, and additional information, it is recommended to refer to the official Honeywell product documentation or contact the manufacturer for further assistance.
