HONEYWELL FC-SAI-1620M

Product Description

Product Parameters

• Input Voltage: 5 VDC (35 mA), 24 VDC (35 mA)
• Input Range: 0 – 4.1 V
• Input Resistance: > 1 MΩ
• Absolute Max. Input Signal: ± 36 VDC
• Number of Input Channels: 16
• A/D Converter: 12 – bit resolution
• Module Inaccuracy: < 0.25%
• Approval: CE, TUV, UL, CSA, FM
• Operating Temperature5: – 10 °C to + 50 °C
• Operating Humidity5: 10% to 90% RH (non – condensing)

Advantages and Characteristics

• High Reliability: The Honeywell FC – SAI – 1620M has approvals from multiple international safety organizations such as CE, TUV, UL, CSA, and FM, which indicates its high reliability in safety – critical applications. It is designed to withstand harsh industrial environments and ensure stable operation. For example, in an oil and gas production plant, it can continuously monitor analog signals related to pressure, temperature, etc. under complex working conditions, providing accurate data without failure for a long time.
• High – Precision Measurement: With a 12 – bit A/D converter, it can achieve high – precision analog – to – digital conversion, ensuring accurate measurement of input analog signals. The module inaccuracy is less than 0.25%, which can meet the high – precision measurement requirements of most industrial applications.
• Good Compatibility: It is compatible with a variety of industrial control systems and can be easily integrated into existing automation systems, reducing the cost and complexity of system upgrades and expansions.

Application Areas and Application Cases

• Application Areas: The FC – SAI – 1620M is suitable for a variety of industries, including oil and gas, marine, power generation, chemical industry, and manufacturing. In these industries, it is used to monitor and control various analog signals, such as temperature, pressure, flow, and voltage.
• Application Case: In a power generation plant, the Honeywell FC – SAI – 1620M is used to monitor the temperature and pressure signals of the steam turbine. By accurately measuring these analog signals, the control system can timely adjust the operating status of the steam turbine to ensure its safe and efficient operation. The high – precision measurement and reliable performance of the FC – SAI – 1620M help to improve the overall operation efficiency of the power generation plant and reduce the risk of equipment failure.

Comparison with Competitors

Selection Suggestions

• Compatibility: Before selecting the FC – SAI – 1620M, make sure that it is compatible with your existing industrial control system, including the controller, communication protocol, and software.
• Installation Environment: Consider the installation environment, such as temperature, humidity, and vibration. The FC – SAI – 1620M is suitable for an operating temperature range of – 10 °C to + 50 °C and an operating humidity range of 10% to 90% RH (non – condensing)5. If the installation environment exceeds these ranges, additional measures may be required to ensure its normal operation.
• Budget: Although the Honeywell FC – SAI – 1620M offers high performance and reliability, it is also necessary to consider the budget. Evaluate the cost – effectiveness of the product based on your actual needs and financial situation.

Precautions

• Installation: During installation, follow the manufacturer’s instructions and relevant safety regulations. Make sure that the power supply is properly connected and the wiring is correct to avoid electrical shock and other safety hazards.
• Maintenance: Regularly check the operating status of the FC – SAI – 1620M, including the input signals, power supply, and communication connection. Clean the module regularly to prevent dust and dirt from affecting its performance. If any faults or abnormalities are found, repair or replace the module in a timely manner.
