HMIGTO5310

Description

series
Product line: Harmony GTO
trait
Multiple communication functions: Support a variety of communication protocols, easy to connect and communicate with different devices.
High resolution display: Provides 640 x 480 pixel VGA resolution for a clear display.
Long life backlight: Backlight life of up to 50,000 hours to ensure long-term stable operation.
High sensitivity touch screen: resistive film touch screen, support 1 million touches, sensitive response.
Rich character fonts: Support simplified Chinese, traditional Chinese, Japanese (ANK, Kanji), Korean ASCII and other character fonts.

argument
Brand: Schneider Electric
Model: HMIGTO5310
Display color: 65536 colors
Display size: 10.4 inches
Display resolution: 640 x 480 pixels VGA
Touch-sensitive area: 1024 x 1024
Power supply: External (source), 24V DC (rated), voltage range 19.2V to 28.8V
Battery: Lithium battery, suitable for internal RAM, autonomous 100 days, charging time 5 days, battery life 10 years
Power consumption: 12W (when the power is not supplied to external devices), 7W (when the backlight is off), 8W (when the backlight is dimmed), 17W (Max)
specification
Product Type: Advanced touch panel
Display type: backlit color TFT LCD
Touch sensing technology: Resistance film, can withstand 1 million touches
Backlight life: 50,000 hours
Brightness: 16 levels adjustable, controlled by touch panel and software
Communication protocol: Supports a variety of protocols, including Modbus, Modbus Plus, FIPWAY, Uni-TE, etc
Memory: Flash EPROM, 96 MB; Internal RAM (SRAM) Data storage device SD card, <= 32 GB SDHC card
Size and weight
External dimensions: W272.5 x H214.5 x D57 mm (W10.73 x H8.44 x D2.24 inches)
Panel opening size: W259 x H201 mm (W10.2 x H7.91 in)
Panel thickness range: 1.6 to 5.0 mm (0.06 to 0.20 in)
Weight: Approx. 2.694 kg
series
Product line: Harmony GTO

effect
Human-computer interaction: As an interactive interface between the user and the system, it realizes the conversion between the internal form of information and the acceptable form of human beings.
Information display: Display various process data, equipment status and other information through high-resolution display.
Operation control: Support touch operation, users can operate and control the device through the touch screen.
System integration: as part of the industrial automation system, integration with other equipment and control systems to achieve automated control.
