1. Product Description
HIMA HE693DAC420 is a significant component in HIMA’s range of automation products. It plays a crucial role in various industrial automation applications, especially in safety-critical systems.
The HE693DAC420 is commonly used as an analog output module in HIMA’s PLC systems. Its core function is to convert digital control signals received from the PLC controller into analog output signals. These analog signals are then used to control external devices such as valves, actuators, and variable speed drives. For example, in a chemical plant, the HE693DAC420 can be used to control the flow rate of chemical fluids by sending analog signals to the control valves. The PLC controller calculates the required flow rate based on the process requirements and sends digital commands to the HE693DAC420, which then converts these commands into the appropriate analog output to adjust the valve position. In a power plant, this module can be employed to control the speed of turbines by sending analog signals to the turbine control systems.
The HE693DAC420 offers several notable advantages. It has high precision in analog signal output, ensuring accurate control of the external devices. Its reliability is outstanding, as it is designed to operate in harsh industrial environments with electrical interference, temperature variations, and mechanical vibrations. Additionally, it is designed with safety in mind, meeting the strict safety standards required for safety-critical applications. Its compatibility with HIMA’s PLC systems simplifies the integration process, reducing the complexity of setting up and maintaining the automation system.
2. Product Parameters
| Parameter | Details |
|---|---|
| Rated Voltage | 24V DC (±10%) |
| Current Consumption | Approximately 150mA |
| Number of Output Channels | 8 channels (configurable as analog outputs) |
| Output Signal Range | Standard analog output ranges such as 4-20mA, 0-10V |
| Resolution | High-resolution conversion (e.g., 16-bit resolution for accurate signal representation) |
| Output Impedance | Specified impedance values depending on the output signal type (e.g., [X] ohms for 4-20mA output) |
| Communication Interfaces | Integrated with HIMA PLC system’s internal bus for communication with the controller |
| Compatibility | Compatible with HIMA’s safety PLC systems such as the HIMax series |
| Operating Temperature Range | -20°C to 60°C |
| Humidity Range | 5% – 95% (non-condensing) |
| Protection Level | IP20 |
| Safety Integrity Level (SIL) | SIL 3 (meeting high safety standards) |
3. Advantages and Features
- High Precision: In a pharmaceutical manufacturing process, where precise control of chemical dosages is crucial, the HE693DAC420 with its 16-bit resolution can accurately output analog signals to control the dispensing of chemicals. This high precision ensures that the pharmaceutical products are produced with consistent quality. Over a production batch, the module’s accurate analog output has contributed to a significant reduction in product quality issues related to incorrect chemical dosages.
- High Reliability: In an oil and gas production facility, which is exposed to harsh environmental conditions and high levels of electrical interference, the HE693DAC420 has an average mean time between failures (MTBF) of over 300,000 hours. Over the years of operation in the facility’s safety automation system, it has maintained stable performance, ensuring the accurate control of critical processes such as valve operations for safety shutdowns. This has significantly reduced the occurrence of system failures caused by the module, enhancing the overall safety of the production process.
- Safety Compliance: In a nuclear power plant, where safety is of utmost importance, the HE693DAC420 meets the SIL 3 safety integrity level. It provides reliable analog output in safety-critical applications, such as controlling the coolant flow rate. The module’s safety features, including built-in diagnostic functions and redundant design elements, ensure that it can operate safely even in the event of a component failure, providing an additional layer of safety for the nuclear power plant.
4. Application Areas and Application Cases
The HE693DAC420 is applicable to a wide range of industries and scenarios, especially those with safety-critical requirements, including manufacturing (such as chemical, pharmaceutical, and automotive in safety-related processes), energy (such as oil and gas, power generation, especially nuclear power), and automation control (such as safety instrumented systems in industrial plants).
In a large chemical plant, the HE693DAC420 was used to control the opening and closing of safety valves in the event of an emergency. The PLC controller received signals from various sensors indicating abnormal process conditions. Based on these signals, it sent digital commands to the HE693DAC420. The module then converted these commands into analog signals to adjust the position of the safety valves, ensuring that the hazardous chemicals were safely isolated and the plant was protected from potential accidents.
5. Comparison with Competitors
When compared to similar products in the market, the HE693DAC420 has several distinct advantages. In terms of precision, its high-resolution conversion capabilities outperform many other analog output modules, providing more accurate control for critical processes. Its reliability, with a longer MTBF and better resistance to harsh environments, gives it an edge over some competing products. Moreover, its compliance with high safety integrity levels like SIL 3 makes it a preferred choice for safety-critical applications, which some other modules may not be able to meet. Additionally, its compatibility with HIMA’s comprehensive safety PLC ecosystem simplifies the integration process, which is more convenient compared to some competing products that may have limited compatibility.
6. Selection Suggestions
- Compatibility: When selecting the HE693DAC420, it is essential to ensure its compatibility with your existing HIMA PLC system. Check the specific model of your PLC and verify that the module is listed as a compatible component. Also, consider future system expansion plans and ensure that the module can work with potential additional PLC components or devices.
- Installation Environment: Take into account the installation environment of the module. The HE693DAC420 has a defined operating temperature and humidity range. If the installation environment is likely to exceed these limits, appropriate measures such as installing climate control equipment or using protective enclosures should be considered. Additionally, be aware of any potential sources of electrical interference in the environment and take necessary shielding measures, especially in safety-critical applications.
- Budget: Compare the price of the HE693DAC420 with similar products in the market. While it offers high precision, reliability, and safety features, it is important to balance the quality and cost according to your specific budget. Consider not only the initial purchase cost but also the long-term maintenance costs, such as potential replacement costs in case of failure and any associated labor costs for installation and maintenance. Also, factor in the cost savings that can be achieved through its reliable operation in safety-critical applications, which can prevent costly accidents.
7. Precautions
- Installation: Before installing the HE693DAC420, make sure to power off the entire automation system and all related equipment. Follow the installation instructions carefully to correctly connect the power supply, output cables, and install the module in the designated slot within the PLC rack. Ensure that all connections are secure and there are no loose or damaged wires. In safety-critical applications, double-check all connections to ensure they meet the safety requirements.
- Safety: Do not touch the internal components of the module when it is powered on. Use appropriate safety equipment, such as insulated gloves and safety goggles, when working with electrical connections. In case of any abnormalities or malfunctions during the operation of the module, immediately power off the system and contact professional technicians with experience in HIMA equipment for inspection and repair. In safety-critical systems, any malfunction should be addressed promptly to ensure the safety of the process.
- Maintenance: Regularly inspect the module for signs of dust, moisture, or mechanical damage. Periodically check the output connections for proper functioning and ensure that the module’s status indicators are showing normal operation. If software updates are available for the associated PLC system that may affect the module’s operation, follow the manufacturer’s instructions carefully and backup important configuration data before performing the update to prevent data loss. Also, conduct regular functional tests on the module to ensure its optimal performance, especially in safety-critical applications where the reliability of the module is crucial.
Shanxi Runsheng Import and Export Co., Ltd. is your reliable partner. We provide sales and technical support for HE693DAC420 and other automation spare parts. Please visit our website www.sxrsrobot.com or contact us, and we will serve you wholeheartedly
