Description
Parameters and Specifications:
–Model Number: HD22010-3
–Manufacturer: Emerson Network Power1
–Input Voltage: 380-400V AC, 6A, 3W+PE, 45HZ-65HZ12
–Output Voltage: 220V DC, 10A31
–Operating Temperature: -10°C to 40°C34
Dimensions and Weight:
–Dimensions: 413mm x 110mm x 257mm (Length x Width x Height)12
–Weight: Approximately 10kg (gross weight with packaging)1, ≤8.5kg (module weight)4
Series:
- Part of Emerson’s HD series of charging modules, specifically designed for power supply systems31
Features:
–Dual Cooling System: Self-cooling for light loads and forced air cooling for heavier loads, ensuring optimal performance in various conditions37
–Protection Functions: Includes input over/under-voltage protection, output over-voltage protection, short-circuit protection, and over-temperature protection37
–Communication Capabilities: Supports RS485 communication protocol, allowing for remote monitoring and control37
–LED Display Panel: Provides real-time information on voltage, current, and alarm status3
–Adjustable Output Voltage: Manual voltage adjustment capabilities for precise control3
Functions and Applications:
–Charging and Power Supply: Primarily used as a charging module in power supply systems for 35kV to 330kV substations32
–Power Management: Ensures stable and reliable power supply for critical electrical equipment and systems3
–System Integration: Easily integrates into existing power management and automation systems3
–Safety and Efficiency: Improves system safety and efficiency by providing precise power control and comprehensive protection features
