Description
Parameters:
Position proportional gain: Set the proportional gain of the position ring regulator. The larger the setting value, the higher the gain and the higher the stiffness. Under the condition of the same frequency command pulse, the smaller the position lag. However, too large a value may cause oscillation or overshoot, and the parameter value is determined by the specific servo system model and load.
Position feedforward gain: Set the position loop’s feedforward gain. The larger the set value, the smaller the position lag under any frequency of instruction pulse. The feedforward gain of the position loop is large, and the high-speed response characteristic of the control system is improved, but the position of the system is unstable and easy to oscillate. When high response characteristics are not required, this parameter is usually set to 0.
Specifications:
Suitable for the mid-power range, with a control unit slot that provides a variety of interfaces for connecting to automated environments for encoder systems, security technologies, and other digital and analog signals.
Power range from 1.5 kW to 11 kW, current range from 12 A to 70 A, DC supply range from 200 V to 500 V.
Size and weight:
Overall dimension: 132mm105mm52mm.
Net weight: 800g.
Series:
The IndraDrive C(HCS02) converter belongs to the product family of Bosch REXROTH.
Features:
The servo driver uses digital signal processor (DSP) as the control core to realize digitalization, networking and intelligence.
Compact design for single axis applications.
With 2.5 times the overload capacity.
Functions:
REXROTH HCS02.1E-W0054-A-03-NNNN servo driver is a controller used to control servo motors, similar to the frequency converter acting on ordinary AC motors, is part of the servo system.
Mainly used in high-precision positioning system, through the position, speed and torque three ways to control the servo motor, to achieve high-precision positioning of the drive system.
It is widely used in industrial robots, CNC machining centers, injection molding machines, textile machinery, packaging machinery and CNC machine tools and other automation equipment.
