GU-D08

Description

Parameters and Specifications:

Control Principle: The GU-D08 features an optimized design based on the standard semiconductor characteristic graphic instrument. It offers high reliability, small size, and ease of use.
Measurement Capabilities: It has the ability to alternately display both the forward and reverse characteristic curves of diodes.
Voltage and Current Range: The collector scan voltage can reach up to 5kV, and the current can reach 2A, suitable for testing various semiconductor devices in household appliances.
Applicable Devices: It is suitable for testing and parameter setting of devices such as transistors, diodes, field effect tubes, thyristors, voltage stabilizer tubes, and three-terminal voltage stabilizer tubes.

Dimensions and Weight:

Dimensions: The GU-D08 has an overall dimension of 310 × 138 × 400mm.
Weight: It weighs approximately 18kg.

GU-D08

Features:

Compact and Reliable: Its compact size and high reliability make it suitable for integration into various industrial automation systems.
Versatile Measurement: Its alternating measurement display function allows for comprehensive testing of semiconductor devices.
Precision and Accuracy: With precise specifications such as the error ranges for collector voltage and current, it ensures accurate testing and measurement.
