GE SR750-P5-G5-S5-HI-A20-R

Description

Parameters and Specifications:

• Brand: General Electric (GE)
• Model: SR750-P5-G5-S5-HI-A20-R
• Platform: Based on GE Multilin P5 platform¹⁶
• Input Channels: 5 switching input channels¹
• Output Channels: 5 switching output channels¹
• Voltage Range: Designed for high voltage (HV) grid¹
• Analog Input Channels: 20¹
• Record Function: Yes¹²
• Actuator Type: Electrical¹

Dimensions:

• Approximate length: Seven inches
• Approximate width: Six inches half
• Approximate height: Eight inches half³

Weight: Not specified in the search results.

Series:

• GE Multilin P5 series¹²³

Features:

• Protection Functions:
  • Overcurrent protection¹
  • Overvoltage protection¹
  • Undervoltage protection¹
  • Transient protection¹
  • Ground fault protection¹
  • Deviation protection¹
• Communication: Supports modern communication protocols such as Modbus, IEC 61850¹
• Monitoring: Has built-in monitoring functions like trip counter, metering, oscilloscope, and data recording⁴
• Power Supply: Voltage range from 88-300VDC, 70-265VAC⁴
• Environmental Tolerance: Suitable for harsh chemical environments⁴
• Interfaces: Multiple network interfaces including Ethernet, RS232, RS485, and RS422 ports⁴
• Front Panel: Includes RS-232 program port interface, LCD display, digital keypad, and control/programming keys⁴

Role and Function:

• SR750-P5-G5-S5-HI-A20-R is a feeder protection relay designed to manage and protect the distribution system³⁴. It can detect various faults in the grid and切断 (disconnect) the faulty lines to protect the equipment¹. It also reduces the need for additional monitoring and metering devices due to its built-in monitoring capabilities².
