GE M2LR-00-000-0

Description

Parameters and Specifications:

• Brand: GE (General Electric)¹²³⁴
• Model: M2LR-00-000-0¹²³⁴
• Type: Online Dew Point Transmitter³⁴
• Measurement Range: -110°C to +20°C¹²³
• Measurement Accuracy: ±2°C (-65°C to +20°C), ±3°C (-110°C to -66°C)¹³
• Measurement Object: Gas¹²³
• Temperature Range: -40°C to +60°C¹²³
• Output: 4~20mA³
• Resolution: Not Specified²³
• Voltage: 24VDC/220VAC³
• Power: Not Specified²³
• Repeatability: ±0.5°C (-65°C to +20°C), ±1.0°C (-110°C to -66°C)³
• Recommended Recalibration Period: 6 to 12 months, depending on application³
• Max Operating Pressure: 0 to 345BAR³
• Storage Temperature: Up to +70°C³

Dimensions and Weight:

• Size: Not Specified (mm)²³
• Weight: 0.7 kg

Series:

• Part of the GE’s line of sensors and measurement devices¹²³

Features:

• High Sensitivity: Utilizes thin-film alumina humidity sensing technology for fast response and calibration stability³
• NIST Traceable Calibration: Each TF series TF2R dew point instrument water probe is calibrated individually by one of the leading water calibration devices. All data is collected and stored by a dedicated computer system, and calibration is repeated for several months to determine the stability of each water probe⁶
• Compact Design: Designed for measuring dew point in dry air devices³
• IP66 Protection: Outer shell protection

Applications:

• Used in industries such as metallurgy, chemical, petrochemical, steel, power, and aviation⁴
• For measuring and monitoring dew point temperature in gases
