Description
GE IS220PTCCH2B Parameters, Specifications, Dimensions, Weight, Series, Features, and Applications (English)
Parameters and Specifications (参数和规格):
Type: GE IS220PTCCH2B is a thermocouple input module designed for use in industrial automation systems.
Compatibility: It is compatible with the Mark VI/Mark VIe systems developed by GE for managing and controlling gas, water, and steam industrial turbine systems.
Input Capability: The module supports E, J, K, S, and T standard thermocouples as well as mV inputs ranging from -8 to 45 mV.
Error Range: It provides a maximum software error/consistency error of 0.25 Fahrenheit.
Dimensions (尺寸):
The exact dimensions of the GE IS220PTCCH2B are not provided in the search results. However, it is typically mentioned as having a size of 16*13*6, which may refer to its length, width, and height or some other measurement standard.
Weight (重量):
The weight of the GE IS220PTCCH2B is not specifically mentioned in the search results. Weight details are typically provided in the product’s technical documentation.
Series (系列):
The GE IS220PTCCH2B belongs to the series of GE Boards & Turbine Control modules.
Features (特征):
Redundancy Support: The module can be used in simplex, duplex, and triple modular redundancy applications.
Common Mode Voltage and Rejection: It has a common mode voltage of +/-5V and an AC common mode rejection of 100dB at 50/60Hz.
Power-On Self-Test (POST): Performs multiple self-diagnostics, including a power-on self-test for the flash memory, RAM, processor board hardware, and Ethernet port.
Environmental Durability: Designed to operate in environmental conditions ranging from -22 to +149 Fahrenheit.
Applications (作用):
The GE IS220PTCCH2B is primarily used in industrial automation and turbine control systems. It provides precise thermocouple input functionality for monitoring and controlling industrial turbines and related processes.
Please note that for accurate and up-to-date information on the GE IS220PTCCH2B module, it’s essential to consult the manufacturer’s official documentation or contact their technical support team. This will ensure you have the most reliable and detailed information available.
