Description
The GE IS200TRPAH2AHE is a digital input module specifically designed for use in various electrical systems, including those found in the electroplating and electrolytic industries. Here is a breakdown of its parameters, specifications, dimensions, weight, series, features, and functions in English:
Parameters and Specifications:
Supply Voltage: +5V DC ±5%.
Input Current: 25mA.
Output Current: Maximum of 1A.
Input Voltage Range: Maximum of 30VDC.
Output Voltage Range: Maximum of 30VDC.
Operating Temperature: 0℃ to 60℃.
Dimensions and Weight:
Dimensions: No exact dimensions are provided in the available sources. However, for reference, it may be comparable to similar modules in size.
Weight: The weight is approximately 0.82 kg.
Series:
The IS200TRPAH2AHE belongs to the GE series of control components and modules.
Features:
Input Non-Saturation: Thanks to its rogowski principle, the module has a wide input range without compromising performance.
Fast Response Time: With a response time reaching microsecond (us) level, it can be effectively used in power system fault recording applications.
Wide Frequency Response: Its frequency range exceeds 20khz, suitable for input signals with complex waveforms.
Good Linearity: The output linearity of the module can reach 0.2%, accurately reflecting the size of the input signal.
High Accuracy: The overall accuracy of the module is within 1%.
Compact and Lightweight: Compared to traditional transducer principles and Hall effect-based products, the IS200TRPAH2AHE has a smaller size and lighter weight for the same input range.
Function/Role:
Electrical System Monitoring and Control: The IS200TRPAH2AHE digital input module is designed to monitor and control electrical systems, particularly in electroplating and electrolytic industries, where accurate measurement and control of large currents are crucial.
Signal Acquisition and Processing: It acquires digital input signals and processes them for use in control systems, enabling precise and reliable control operations.
