GE IC697CPX782
GE IC697CPX782 is a high – performance central processing unit designed for the GE Fanuc Series 90 – 70 programmable logic controllers ( PLCs ). It is equipped with an 80486 DX4 microprocessor, which offers powerful processing capabilities. This module is capable of performing floating – point calculations, facilitating complex arithmetic operations required in industrial automation1. It uses MS – DOS or Windows – based programming software to control machines, processes, and systems1. With 1 MB of battery – backed CMOS RAM and 256 KB of non – volatile user flash memory, it can store program data and configuration information securely1. The module also features three independent serial ports, which support various communication protocols such as RS – 232 and RS – 485, enabling seamless connection with other devices5.
Product Parameters
- Power Supply1: It requires a 100 W AC/DC power supply and a 90 W DC power supply.
- Current5: The nominal current required is 3.1 amps from a 5 – volt bus.
- Memory5: It has 1 MB of battery – backed RAM and 256 KB of non – volatile user flash memory.
- Serial Ports5: There are three serial ports, with port 1 supporting RS – 232 communication and ports 2 and 3 supporting RS – 485 communication.
- Compatibility5: It is compatible with GE Fanuc 90 – 70 PLCs and supports IC660/IC661 I/O and IC697 I/O.
- Clock Accuracy1: The day clock accuracy is within 3.5 seconds per day, and the elapsed time clock accuracy is within 0.01%.
Advantages and Characteristics
- High – Speed Processing: With a 96 – MHz clock speed, the IC697CPX782 can execute boolean functions at a rate of 0.4 microseconds per function, enabling it to handle complex control tasks with high efficiency5.
- Reliable Memory: The combination of battery – backed RAM and non – volatile flash memory ensures that data is retained even in the event of a power outage, enhancing the reliability of the system1.
- Versatile Communication: The three serial ports support multiple communication protocols, providing flexible connectivity options for integrating with other devices and systems in an industrial automation network5.
Application Areas and Application Cases
- Applicable Industries: This module is widely used in various industries, including manufacturing, energy, and automation control. In manufacturing, it can be used to control production lines, robotic arms, and conveyor belts. In the energy sector, it can be applied to monitor and control power generation equipment, such as turbines and generators. In automation control systems, it serves as the core processing unit for complex logic operations and data processing.
- Application Case: In a manufacturing plant, the GE IC697CPX782 is used to control a robotic arm that performs precise welding tasks. The high – speed processing capability of the module allows it to quickly calculate the movement trajectories and welding parameters of the robotic arm, ensuring accurate and efficient welding. The reliable memory and communication functions also ensure that the control program and welding data are stable and can be transmitted in a timely manner, improving the overall production quality and efficiency.
Competitor Comparison
Compared with similar products, the GE IC697CPX782 offers several advantages. It has a relatively high – speed microprocessor, which enables faster processing and response times, thereby improving the overall efficiency of the control system. Its rich memory resources and reliable memory protection mechanism ensure the security and integrity of data. In addition, its wide range of communication interface support provides greater convenience and flexibility for system integration.
Selection Suggestions
- Compatibility: Ensure that the selected module is compatible with your existing GE Fanuc Series 90 – 70 PLC system and other related equipment to avoid compatibility issues.
- Processing Capability: Consider the complexity of the control tasks. If the tasks involve a large number of floating – point calculations and complex logic operations, the IC697CPX782 is a suitable choice due to its powerful processing capabilities.
- Memory Requirements: Evaluate the amount of data that needs to be stored and processed. The IC697CPX782’s 1 MB of RAM and 256 KB of non – volatile flash memory can meet the needs of most applications, but if more memory is required, additional expansion may be necessary.
- Budget: The price of the IC697CPX782 should be considered in combination with your budget. Although it offers high performance and reliability, it is necessary to ensure that it is within your financial capacity.
Precautions
- Installation: When installing the module, make sure to follow the installation instructions carefully and ensure that the power supply and communication connections are correct. Avoid installing it in an environment with strong electromagnetic interference, high temperature, or high humidity.
- Maintenance: Regularly check the status of the module, including the power supply, memory, and communication ports. Replace the lithium battery in a timely manner to ensure the normal operation of the calendar clock and data retention. Keep the module clean and free of dust and debris to prevent damage to the internal components.
Shanxi Runsheng Import and Export Co., Ltd. is your reliable partner. We provide the sales and technical support of GE IC697CPX782 and other automation spare parts. Please visit our website www.sxrsrobot.com or contact us, and we will be happy to serve you.
