Description
The GE IC697CPM790 is a high-performance CPU processor module specifically designed for industrial automation and control systems. Here are its key parameters, specifications, dimensions, weight, series, features, and functions described in English:
Parameters and Specifications:
Processor Type: It features a 64 MHz, 32-bit floating-point CPU (IC697CPM790) with 1 MB of memory.
Operating System: The module utilizes a dedicated flash memory for the operating system firmware, allowing for firmware updates through the connection between the PC and the module’s serial port.
Input/Output Capacity: It includes up to 12K discrete inputs and outputs, operating in a mixed simplex mode.
Dimensions and Weight:
Dimensions: The module’s size and shape are standardized for easy integration into various devices. However, specific dimensions may vary based on the manufacturer’s specifications.
Weight: The weight of the IC697CPM790 module can also vary, and it is recommended to consult the manufacturer’s documentation for accurate weight information.
Series:
The IC697CPM790 belongs to the GE Fanuc series 90-70 CPU family.
Features:
High Performance: The 64 MHz CPU with 32-bit floating-point capabilities ensures high-speed processing and efficient operation.
Flexible Programming: It supports single-slot programming software compatible with Windows or MS-DOS, enabling convenient configuration and programming.
Robust and Reliable: The module’s design ensures reliability and stability, making it suitable for mission-critical industrial applications.
Memory Protection: Memory protection keys or software passwords provide secure access and protection for configuration and program data.
Multi-functional LED Indicators: Four green LEDs indicate the CPU’s status, providing visual feedback on the module’s operational state.
Extensive Connectivity: The module offers a 15-pin D-type connector for serial port communication, compatible with RS-485.
Redundant Operation: It supports triple module redundancy (TMR) operation and automatic test routines for enhanced system reliability.
Role/Functions:
Central Processing Unit: The IC697CPM790 serves as the core processing unit in industrial automation systems, handling complex control logic, data acquisition, processing, and output control.
System Integration: It facilitates seamless integration with other modules and devices within the system, enabling efficient data exchange and communication.
Real-time Monitoring: With its ability to monitor and validate the system configuration, it ensures the accurate and reliable operation of the overall system.
Fault Detection and Alarm: It features alarm functionality that reports any deviations in the programming or actual system configuration, assisting in timely fault detection and mitigation.
