Description
GE IC697CPM790 Parameters, Specifications, Dimensions, Weight, Series, Features, and Applications (English)
Parameters:
Processor Type: A 64 MHz, 32-bit floating-point processor (CPU) with 1 MB of memory.
Clock Speed: 64 MHz.
Memory: 1 MB of battery-backed memory for data retention.
Specifications:
Discrete Input/Output: Up to 12K discrete inputs and outputs in a mixed simplex method.
Firmware Update: Supports firmware updates through the connection between the PC and the module’s serial port.
Operating Voltage: Compatible with various voltages, such as 12-48VDC for input and 5VDC for output.
Output Current: Maximum output current capability of 10A.
Efficiency: Greater than 90% efficiency.
Dimensions and Weight:
Dimensions: Approximately 170mm x 105mm x 32mm.
Weight: About 120g.
Series:
GE IC697CPM790 belongs to the GE Fanuc 90-70 series of PLC (Programmable Logic Controller) modules.
Features:
Triple Module Redundancy (TMR): Supports TMR operation and automatic test routines, enhancing system reliability.
Single-Slot Programming: Allows configuration and programming using Windows or MS-DOS with its single-slot programming software.
Memory Protection: Incorporates memory protection keys or software passwords to secure configuration and program data.
LED Indicators: Has four green LEDs to indicate CPU status.
Cooling: Requires a fan component for air cooling.
Communication: Supports RS-485 communication protocol for serial port connections.
Alarm Function: Detects and reports any deviations in programming or practical configurations during operation and power-on.
Calendar Clock Operation: Maintains calendar clock operation, data storage, and program memory with a lithium battery.
Applications:
GE IC697CPM790 is widely used in industrial automation and control systems, where it performs various functions such as data processing, control logic implementation, and system monitoring.
It is suitable for applications that require high reliability, efficiency, and precision control, such as power generation, energy, chemicals, pharmaceuticals, and food processing industries.
Please note that the specifications, dimensions, and weights provided may vary depending on the specific model or version. It is always advisable to refer to the latest official product documentation or contact the manufacturer’s technical support for accurate and up-to-date information on the GE IC697CPM790.
