Description
The GE IC695PBM300 is a PROFIBUS master module designed for industrial automation applications, specifically within the PACSystems RX3i platform. Here is a breakdown of its parameters, specifications, dimensions, weight, series, features, and applications in English:
Parameters:
Compatibility: The module requires an RX3i CPU with firmware version 2.9 or higher.
Configuration Software: It requires Machine Edition SP5 Logic Developer PLC software version 0.2 or higher for configuration.
Specifications:
Data Rates: Supports all standard data rates, including 1.5, 3, 6, 12, 9.6, 19.2, 187.5, 93.75, and 500 MB/s.
Communication Ports: Features an RS-232 communication port.
Memory Capacity: Can configure data with up to 3,584 bytes of input and 3,584 bytes of output.
Backplane Current: Consumes 440 mA at 3.3 V DC.
Dimensions and Weight:
The module’s dimensions are typically compact, suitable for rack-mounting within automation systems.
Exact dimensions and weight may vary, but they are typically designed for easy integration into industrial cabinets.
Series:
The IC695PBM300 belongs to the PACSystems RX3i series of communication modules.
Features:
PROFIBUS Compatibility: Supports communication with up to 125 PROFIBUS-DP slaves.
LED Indicators: Provides three LEDs for indicating module and network status.
Synchronization and Freeze Modes: Supports synchronization and freeze modes for PROFIBUS communication.
Firmware Upgradability: The module’s firmware can be upgraded through the host controller using WinLoader software.
Applications:
The GE IC695PBM300 is used in industrial automation systems where PROFIBUS communication is required. It allows the RX3i CPU to send and receive data on the PROFIBUS-DP network, enabling seamless communication and control between various devices and components within the system.
