Description
Parameters and Specifications
- User Memory: 64MB123
- I/O: 32k bits of discrete I/O and 32k words of analog I/O123
- Ethernet Ports: 3 ports with 10/100/1000 Mbps (2 switched ports)236
- Ethernet Protocols: SRTP Client/Server, Modbus TCP/IP, OPC UA, EGD, PROFINET, DNP3, IEC-61850 Client, IEC-104 Server, etc.123
- Serial Protocols: ASCII Serial Protocol, Modbus/RTU123
- USB Interface: 1 USB-A 2.0123
- Storage Card: 1 CFast123
- Operating Environment: 0 to 60℃123
- Agency Certifications: UKCA, UL, cUL, RoHS, CCC, FCC, Reach, ATEX Zone 2, etc.12
- Maritime Certifications: ABS, BV, LRDNV GL12
Dimensions and Weight
- Dimensions and Weight: Not specifically mentioned in the provided information.
Series
- Series: RX3i Series
Features
- PLC Control: Executes control logic and programs in PLC systems1.
- Communication Interface: Supports multiple communication interfaces for data exchange with other PLC modules, external devices, or upper-level control systems1.
- Programmable: Allows users to write and upload custom control programs using appropriate programming software4.
- Real-time Monitoring: May support real-time monitoring of PLC system status, variables, and alarm information4.
- Redundant Support: Media Redundancy (MRP) and PROFINET System Redundancy (PNSR) supported12.
- Processor Speed: 1 GHz3
- Programming Languages: Supports languages such as Ladder Diagram (LD), Structured Text (ST), Function Block Diagram (FBD), or C3.
- USB 2.0 Port: Allows the use of regular USB drives and smartphones for program uploads and downloads
Applications
- Industrial Automation: Widely used in industries such as manufacturing, process control, and other scenarios requiring automation1.
- Specific Applications: Suitable for ports, heating, gas, water supply, wastewater treatment, and metallurgy5
