Description
The GE IC694MDL645 is a digital input module designed for use in industrial automation systems, specifically within the RX3i PACSystems PLCs. Below is a summary of its key parameters, specifications, dimensions, weight, series, features, and applications in English:
Parameters and Specifications:
Rated Voltage: Nominally 24 VDC with a working range of 0 to 30 VDC.
Input Channels: It features 16 input channels, all grouped in a single set.
Input Current: The input current rating is 80 mA at 5 VDC and 125 mA at 24 VDC.
Operating Temperature: The module operates between 0 to 60 °C (32 to 140 °F).
Storage Temperature: It can be stored in temperatures ranging from -40 to 85 °C (-40 to 185 °F).
Humidity: The module can operate and be stored in environments with a humidity range of 5% to 95% (not condensing).
Dimensions and Weight:
The specific dimensions and weight of the GE IC694MDL645 module may vary depending on the manufacturer and model variant. However, it is designed to fit within standard PLC racks.
Series:
The IC694MDL645 belongs to the RX3i PACSystems series of industrial automation components.
Features:
Flexibility: The module supports both positive and negative logic on all 16 input channels.
Durability: It is designed for use in slightly damp but non-condensing environments.
Compatibility: The module can be installed in RX3i PACSystems PLCs and can be removed while the PLC is powered.
Applications:
The GE IC694MDL645 module is typically used in industrial automation systems to receive digital input signals from sensors, switches, and other devices.
These input signals can then be processed by the PLC to control machinery, monitor processes, or perform other automation tasks.
