GE IC693DNM200

Description

Parameters and Specifications:

• Rated Voltage: 12-24VDC for positive logic, with a forward voltage drop of 0.3 V DC¹.
• Switching Response Time: Up to 0.5 milliseconds¹.
• Output Points: 32 total, with 4 points per group and 8 groups¹.
• Output Current: 0.5 ampere per point, 4 ampere per group, with a maximum of 3 ampere for each group’s common pin¹.
• Surge Current: 5.4 ampere for 10 milliseconds¹.

Dimensions and Weight:

• Weight: Specified as 0.5 pounds².

Series:

• GE 90-30 Series¹.

Features:

• DeviceNet Master: Allows GE PLC to communicate with other devices on a DeviceNet network³.
• Communication Functionality: Enables data exchange and control commands with devices on the DeviceNet network³.
• Integration with PLC: Part of GE’s PLC system, easily integrated into PLC programs for device and system control³.
• Control of Electrical Systems: Used for controlling electrical systems such as generator-transformer groups and factory power supply⁴.

Applications:

• Industrial Automation: Connects and controls various devices and sensors, including Variable Frequency Drive (VFD) modules³.
• Manufacturing: Used in manufacturing, factory automation, logistics, and transportation applications³.
• DCS Monitoring: Included in DCS monitoring for electrical systems in main powerhouses⁴.
