Description
Parameters and specifications:
Measuring principle: Using capacitive electrode and thermal conductivity sensor to measure the concentration of water and hydrogen in oil.
Measurement range: moisture (0-10,000 ppm), hydrogen (0-10,000 ppm). In addition, it can also monitor other fault gases, such as H2, CO, CO2, CH4, C2H4, C2H6, C2H2, O2, etc.
Accuracy: ±10% or ±25 ppm (moisture and hydrogen measurement); ±2% or 2ppm of the reading (other gas measurements, whichever is higher).
Response time: <10 minutes.
Communication interface: RS485, RS232, MODBUS, DNP3, IEC 61850, etc.
Operating temperature range: -40°C~85°C.
Size and weight:
Size: There are two different size descriptions. One is 190 mm x 160 mm x 80 mm; The second is 102mm x 70mm x 15mm (may be another model or component).
Weight: 1.5kg (first size); 110g (second size).
Series:
The GE HYDRAN M2 is a family of products under the GE (General Electric) brand used to monitor the condition of transformers and other power equipment.
Features:
Multiple sensors: A variety of gas sensors may be available to detect different types of faulty gases.
Real-time monitoring and alarm function: With real-time monitoring function, it can continuously monitor the gas concentration and issue an alarm when abnormal conditions are detected.
Remote monitoring: Support remote monitoring function, allowing users to remotely access detector data through the network, and timely processing of abnormal situations.
Data logging: Historical data on the concentration of faulty gases can be recorded for subsequent analysis and review.
Industrial grade design: Durable industrial grade design, suitable for harsh industrial environments.
Functions:
The GE HYDRAN M2 is a fault gas detector used primarily to detect fault gases such as ethylene, acetylene, hydrogen, etc. in transformers and other power equipment to detect potential equipment failures in advance. It can help users find potential equipment failures early and take appropriate measures to ensure the safe operation and reliability of equipment.
