GE DS3800HFXA1D1B

Description

Parameters and Specifications:

• Brand: GE Digital Energy (General Electric Digital Energy)
• Model: DS3800HFXA1D1B
• Main Function: It cuts off and connects current in high-voltage circuits to protect circuits and equipment from damage caused by overload, short circuit, and grounding faults¹.
• Rated Voltage: 3800V
• Rated Current: 1200A¹
• Operating Temperature: (-22°F to +150°F) / (-30°C to +65°C)²
• Storage Temperature: (-40°F to +185°F) / (-40°C to +85°C)³
• Humidity: 95%, noncondensing²
• Hardware Interface: RS422²
• Weight: 0.82 kg³

Dimensions:

• The exact dimensions are not explicitly mentioned in the search results, but it’s likely to be a compact module suitable for industrial applications.

Series:

• The DS3800HFXA1D1B belongs to the GE Digital Energy series of products.

Features:

• Modular Design: Allows for easy installation and replacement.
• High-Voltage Capabilities: Designed to handle high voltage and current levels in industrial environments.
• Protection: Provides protection against overload, short circuit, and grounding faults.
• Compatibility: Likely to be compatible with other GE and third-party industrial automation systems.

Applications:

• Power Systems: Used in electrical power distribution systems to protect and control circuits.
• Industrial Buildings: Found in factories, warehouses, and other industrial facilities for automation and control.
• Commercial Buildings: Also suitable for use in larger commercial buildings where high-voltage power distribution is required.
