Description
The parameters, specifications, dimensions, weight, series, features and functions of GE DS200UPSAG1AGD module can be summarized as follows:
Parameters:
Input type: The module can monitor up to 12 RTD (Resistance Temperature Detector) inputs for stator, bearing, environmental or other temperature monitoring.
RTD Type: Each RTD type can be field-programmed to be 100Ω platinum (DIN 43760), 100Ω nickel, 120Ω nickel or 10Ω copper.
Specifications:
RTD circuit compensation: When using a three-wire RTD, the module automatically compensates the wire resistance.
Lead resistance: The lead resistance should not exceed 25Ω (platinum/nickel type RTD) or 3Ω (copper type RTD) per lead.
Series:
Series: The module is part of GE’s DS200 series, an important family of GE’s industrial automation products.
Features:
Industrial environment adaptability: RTD cables should be close to the grounded metal housing and away from areas of high electromagnetic or radio interference to ensure stable operation in industrial environments.
Modularity and flexibility: The DS200UPSAG1AGD module is a key component in industrial automation systems and integrates seamlessly with other modules and devices, providing flexible scalability and configuration options.
Functions:
The GE DS200UPSAG1AGD module is mainly used for temperature monitoring and control in industrial automation systems. By accurately measuring and monitoring the temperature at different locations, it helps ensure the proper operation of the equipment, preventing overheating and other potential problems, thereby improving production efficiency and equipment reliability.
