Description
The GE DS200TCQAG1A is a模拟 I/O board specifically designed for the Mark V series of industrial automation systems. Here is a summary of its parameters, specifications, dimensions, weight, series, features, and functions in English:
Parameters and Specifications:
Type: Analog Input/Output (I/O) Board
Function: Used for scaling and adjusting signals within the Mark V system, particularly in the R1, R2, and R3 I/O kernels
Supported Signals: Collects and processes signals such as thermocouple inputs, servo valve outputs, vibration inputs, generator/line signals, relay drive outputs, voltage inputs, pulse inputs, and 4-20 mA input/output
Communication: Signals are exchanged with the TCQC board through the JE connector on the DS200TCQAG1A module
Connectors: Features 8 available connectors (JG, JF, JE, JD, JB, JA, 2PL, and 3PL), each serving specific functions
Dimensions and Weight:
Dimensions: Exact dimensions may vary, but it typically fits into standard industrial automation rack systems.
Weight: The exact weight is not provided in the available sources, but it is likely to be within the range of similar industrial automation modules.
Series:
The GE DS200TCQAG1A belongs to the Mark V series of industrial automation components from GE.
Features:
Versatility: Supports a wide range of analog signals, making it suitable for various applications within the Mark V system
Scalability and Adjustment: Able to scale and adjust signals to meet the specific requirements of the industrial process or equipment
Cold End Compensation: Utilizes cold end reference from the thermocouple circuit to calculate cold end compensation within the Mark V system
Robust Connectivity: Multiple connectors provide flexible and reliable signal connections
Role and Function:
The GE DS200TCQAG1A analog I/O board serves as a critical interface between sensors, actuators, and the Mark V control system. It collects analog signals from various sensors and transmitters, converts them into digital formats suitable for processing by the control system, and also converts control signals from the system back into analog formats for actuating devices. This board ensures accurate and reliable signal transmission within the industrial automation system, enabling precise control and monitoring of industrial processes and equipment.
Please note that the specific parameters, specifications, dimensions, weight, and features may vary depending on the manufacturer’s updates or different versions of the module. It is recommended to consult the official GE documentation or contact their technical support team for the most accurate and up-to-date information. Additionally, when installing or using the module, ensure to follow all safety guidelines and procedures provided by the manufacturer.
