Description
The parameters, specifications, dimensions, weight, series, features and functions of GE DS200TCPSG1AME module are as follows:
Parameters and specifications:
Channel status data: The reference address and start address parameters are used to configure the read and reference of channel status data. The number of channel states can be 8 or 16.
Output range: including 0 to 10V, -10 to +10V, 4 to 20mA and 0 to 20mA, users can choose the appropriate output range according to the application needs.
Active channels: indicates the number of channels that the PLC CPU will scan, which is to ensure the effective operation of the system and the accuracy of data acquisition.
Stop mode Output state: When a module switches from RUN mode to STOP mode, it can be configured to remain in the last state or default to zero.
Size and weight:
Weight: The module weighs 0.8KG.
Series:
Series: Part of GE’s DS200 series, this series includes a variety of industrial automation and control products.
Features:
Scope: Suitable for all standard applications and fully functional for heavy duty applications.
Housing: Extremely flexible anodized aluminum housing, stainless steel variant, not affected by dust and oil.
Communication mode: The controller and I/O module communicate with each other through IONet.
Interface: Ethernet network interface, straight plug interface mode.
Power supply: The power supply is stable, and the input current can be used in non-redundant, dual-redundant, and triple-redundant configurations.
Hardware components: includes multiple fuses, heat sinks, resistance network arrays, TP test points, transformers, inductors, and multiple metal oxide varistors.
Functions:
The DS200TCPSG1AME module plays a key role in the industrial automation system, which is used to receive, process and output analog signals to achieve accurate control of industrial processes. It can convert analog signals into digital signals for system processing, and output corresponding control signals to the actuator according to the control logic. In addition, it also has a variety of protection functions and communication interfaces to ensure the stable operation of the system and reliable transmission of data.
