Description
GE DS200PCCAG10ACB Parameters, Specifications, Dimensions, Weight, Series, Features, and Applications in English
Parameters and Specifications:
Model Number: DS200PCCAG10ACB.
Brand: GE (General Electric).
Type: Analog mixed module with 12-bit +/- 1VDC input current.
Input Channels: Four channels.
Output Channels: Two channels.
Power Supply: Requires 24V external power for the output, and the input is powered by transceiver external power.
Dimensions and Weight:
Dimensions: The exact dimensions may vary depending on the specific packaging and configuration. However, it’s typically a standard module size used in automation systems.
Weight: Approximately 2KG.
Series:
The DS200PCCAG10ACB belongs to a series of analog mixed modules designed for industrial automation applications.
Features:
Input Range: +/- 1VDC input current range.
Output Type: Supports analog output.
LED Indicators: Display analog field side circuit power status and backplane power status.
External Power Range: +18 to +36VDC with a ripple of 16mA.
Shielding Capability: Recommended to use shielded cables when grounding is present on source equipment or I/O modules.
Applications:
The GE DS200PCCAG10ACB is an analog mixed module primarily used in industrial automation systems for precise analog signal processing. It converts analog input signals into digital data for further processing and control. It’s often used in various industries, including power generation, manufacturing, and process control, to monitor and control analog signals effectively.
