The GE DS200NATOG2A is a specific type of control or interface module used in industrial automation and related applications. Here is a summary of its parameters, specifications, dimensions, weight, series, features, and functions in English:
Parameters and Specifications:
Type and Function: DS200NATOG2A is a voltage feedback scaling board, which is a variant of the NATO board. It is designed to provide scaled voltage outputs based on the input voltage received.
Circuitry: The board’s output is obtained through five lines connected to a 20-pin ribbon connector. It also includes metal oxide varistors (MOVs) to prevent excessive output voltages in case of input voltage interruption.
Voltage and Resistance: The board has specific inputs, such as VLL and VLG, with defined voltages (e.g., VLL input of 2200, VLG input of 1270.17) and outputs (e.g., VLG output of 1.905). It also incorporates resistors and jumpers for fine-tuning and adjustment.
Dimensions and Weight:
Dimensions: The exact dimensions of the DS200NATOG2A board are not provided in the search results. However, industrial control boards are typically designed to fit standard racks and cabinets.
Weight: The weight of the DS200NATOG2A board is mentioned as 2KG.
Series:
The DS200NATOG2A belongs to the DS200 series of control or interface modules offered by GE for industrial automation applications.
Features:
Isolation: The DS200NATOG2A may be offered as an isolated 12-bit analog output board, providing electrical isolation for increased safety and reliability.
Lightweight and Compact: Its lightweight and compact design facilitate easy installation and integration into existing systems.
Versatile Connectivity: The board’s ability to interface with various inputs and provide scaled outputs makes it versatile for multiple applications.
Functions and Applications:
Voltage Scaling and Feedback: The DS200NATOG2A board is primarily used for voltage scaling and feedback in industrial automation systems. It converts and scales incoming voltage signals to suitable output levels for further processing or control.
Integration with Automation Systems: The board can be seamlessly integrated into larger automation systems, enabling precise control and monitoring of industrial processes.
Safety and Reliability: Its design, including the use of MOVs and resistors, contributes to improved safety and reliability in industrial environments.
