GE DS200ADGIH1AAA

Description

Parameters and Specifications

• Model: DS200ADGIH1AAA
• Brand: GE (General Electric)
• Series: Mark V DS200¹
• Control Principle: Other²
• Channels: Dual Channel²
• Bandwidth: 100MHz²
• Rise Time: ≤3.5ns²
• Sampling Rate Range: 2GS/s (Single Channel), 1GS/s (Dual Channel)²
• Vertical Deflection Coefficient: 1mV/div ～ 10V/div²
• Record Length: 1024k²
• Sampling Rate (Real-time): 2GS/s²
• Equivalent Sampling Rate: 50GS/s²
• Sweep Time Base: 5ns ～ 50s/div²

Dimensions and Weight

• Width: 8 inches¹³
• Length: 6 inches¹³
• Weight: 1.1kg⁴

Series

• Mark V DS200 series¹

Features

• Multiple Test Points: Provides a method to test the circuits on the board¹.
• Installation: Designed for installation in the cabinet of the drive¹³.
• Interface: Equipped with a 40-pin connector, 60 jumpers, and a 6-pin connector¹.
• Programmable: Allows for customization and adjustment of control logic and parameters⁵⁶.
• Communication Interface: Likely to have various communication interfaces for data exchange and communication with other control systems and monitoring devices

Role

• PLC/DCS Component: GE DS200ADGIH1AAA is a component of PLC (Programmable Logic Controller) or DCS (Distributed Control System) systems¹⁴⁵.
• Control and Monitoring: Used to execute control logic, monitor and adjust the operational status of gas turbines, ensuring their efficient and stable operation⁶.
• Fault Protection: May include fault protection functionality to automatically take measures in case of abnormal conditions, protecting the safe operation of gas turbines⁶.
• Data Recording: Likely to have data recording capabilities to store operational status and fault information for subsequent analysis and maintenance
