FX-316CE

Description

Parameter Specifications

Power Supply: Operates at 24V DC with a tolerance range of ±10%. The power consumption is relatively low, around 1.5W under normal operation.
I/O Configuration: It has 16 digital inputs that can accept signals from 0V to 24V, and 16 digital outputs with a rated load capacity of 2A at 24V DC.
Communication Interfaces: Supports RS-232 and RS-485 communication protocols, enabling seamless connection with other devices and systems. The baud rate for communication can be configured from 9600bps to 115200bps.

Functions

Signal Acquisition: Captures digital signals from various sensors and devices connected to its inputs, providing real-time status information.
Control Output: Controls external equipment such as relays, solenoids, and motors through its digital outputs, enabling precise control of industrial processes.
Data Communication: Transmits and receives data with other controllers or monitoring systems via the available communication interfaces, facilitating system integration and remote monitoring.

Weight and Dimensions

Weight: Weighs approximately 200 grams, which is lightweight and convenient for installation in different locations.
Dimensions: It measures 120mm in length, 80mm in width, and 50mm in height, allowing it to fit into standard control panels and enclosures.

Characteristics

High Reliability: Built with robust circuitry and quality components, it can operate stably in harsh industrial environments with a wide temperature range from -20°C to 60°C.
Flexible Configuration: The I/O and communication parameters can be easily configured through software, providing great flexibility for different application requirements.
Cost-Effective: Offers a good balance of performance and cost, making it an ideal choice for many industrial applications.

Application Areas

Industrial Automation: Widely used in production lines for controlling and monitoring the operation of machinery and equipment.
Building Automation: Applied in smart buildings to control lighting, access control, and HVAC systems.
Transportation: Used in transportation systems for controlling signals, monitoring vehicle status, and managing logistics.
Energy Management: Helps in monitoring and controlling power distribution and consumption in power plants and substations.
