FOXBORO FCP280

Description

Parameters and Specifications:

• Model: FCP280 RH924YA
• Display: 7.0″ TFT LCD with LED backlight, 800×480 resolution, 16.77 million colors, adjustable brightness¹².
• Touch Panel: Four-wire resistive touchscreen, with LCD life of over 50,000 hours¹².
• Memory: 128MB¹².
• External Interfaces:
  • Download port: RS232/RS485/RS422
  • PLC port: RS485 (X-Net bus)
  • USB ports:
    • USB-B (USB 2.0 compliant), for downloads
    • USB-A (USB 2.0 compliant), for U-disk, UT/ET models support Ethernet

• Electrical Characteristics:
  • Input voltage: DC24V (range: DC22V~26V)
  • Consumption current: 200mA
  • Voltage surge withstand: AC1000V, 10mA for less than 1 minute
  • Insulation resistance: Over 10MΩ, DC500V².
• Environmental Conditions:
  • Operating temperature: 0℃ to 50℃²³⁴.
  • Storage temperature: Not specified.

Dimensions and Weight:

• Size: 32cm x unspecified (width and depth not provided)⁴.
• Weight: 0.45kg

Series:

• Foxboro DCS (Distributed Control System) Field Control Processor⁴⁶⁷.

Features:

• High Reliability: Provides unique patented fault-tolerant operation using two control modules⁶⁷.
• Compatibility: Compatible with earlier Foxboro automation platform hardware⁷.
• Capacity and Performance: Capacity is double and performance is triple that of older controllers⁷.
• Flexible Connectivity: Supports standard fiber or 100 Mbps copper cables¹⁶.
• Redundant Communication: Ensures continuous operation even in case of failures⁶⁷.
• Security: Ensures network security through ISA EDSA certification⁴.
• Upgradability: Supports online image upgrades (OLUG) and enhanced online image upgrades (EOLUG)⁶⁷.

Applications:

• Process Automation: Used in industries such as refining, petrochemicals, upstream and midstream oil and gas, chemicals and special chemicals, power generation, metallurgy, mining, water and wastewater treatment, food and beverage, life sciences, and pharmaceuticals
