Description
Parameters and specifications:
Memory size: Has 16 MB SDRAM and 32 MB flash memory.
Input voltage: 24 V dc (redundant voltage).
Power consumption: Maximum 8.5W (per non-fault-tolerant module).
Operating temperature: 0 to +60 degrees Celsius (+32 to +140 degrees Fahrenheit).
Size and weight:
Dimensions: Length 14.7 cm, width 5.15 cm, height 11.4 cm.
Weight: 0.6 kg (shipping weight is 1.5 kg).
Features:
Modular design: Allows modular configurations for flexible combinations based on the needs of a specific application.
Powerful control functions: Adjustment, logic, timing and sequence control can be performed in conjunction with a connected fieldbus module (fbm).
Data acquisition and monitoring: Support data acquisition, alarm detection and notification.
High compatibility: Highly compatible with other Foxboro controllers and devices, enabling flexible networking and integration of the system.
Multiple communication interfaces: Support Ethernet, serial port, Profibus, Modbus and other communication interfaces.
