Description
Parameters and specifications
Memory size: 16 MB SDRAM, 32 MB flash
Input voltage: 24 V DC (typical)
Power consumption: Maximum 8.5W per non-fault-tolerant module
Operating temperature: 0 to +60 degrees Celsius (+32 to +140 degrees Fahrenheit)
Configuration: Single-processor module, fault-tolerant by two processor modules, the substrate integrated into an interconnect fault-tolerant connector
Processor: Possible Microprocessor based AMD Elan 520 100MHz, I/O processor CommControl™ ASIC
Size and weight
Dimensions: Length 14.7cm x width 5.15cm x height 11.4cm
Weight: 0.6 kg (product itself), shipping weight 1.5 kg
trait
Fault-tolerant mechanism: With fault-tolerant operation, the use of two control modules provides unique patented fault-tolerant operation, improving the reliability of the system
Communication capability: Support for connection to grid control networks via standard fiber 100 Mbps Ethernet and support for two 2 Mbps or 268 Kbps HDLC fieldbus networks
Control capabilities: Support the use of a variety of control algorithms and a variety of FBM (Fieldbus modules) to provide control capabilities for various process applications
Time synchronization: Support for time synchronization using optional external time from GPS satellites
Rugged housing: A rugged die-cast aluminum housing designed to work in harsh G3 environments
Scalability: Up to 32 Series 200 FBMS are supported, up to 128 Series 200 FBMS and up to 64 Series 100 FBMS can be supported through the Fieldbus Extension Module (FEM100)
