Description
argument
Memory size: 16 MB SDRAM and 32 MB flash
Input voltage: 24 V DC (typical)
Power consumption: Maximum 8.5W per non-fault-tolerant module
Operating temperature: 0 to +60 degrees Celsius (+32 to +140 degrees Fahrenheit)
specification
Type: Field control processor
Configuration: Single processor module, fault tolerant by two processor modules
Color: Black
Bom number: P0917YZ
Size and weight
Size: 14.7cm x 5.15cm x 11.4cm (L x W x H)
Weight: 0.6 kg
Shipping weight: 1.5 kg
series
The FCP270 is a product of FOXBORO Corporation, commonly classified as its family of field control processors.
trait
Fault-tolerant mechanism: The use of two control modules provides a unique patented fault-tolerant operation that greatly improves reliability compared to other process controllers
Communication capability: Connected to the grid control network via standard fiber 100 Mbps Ethernet, supporting two 2 Mbps or 268 Kbps HDLC fieldbuses
Scalability: Up to 32 Series 200 FBMS can be supported, and up to 128 Series 200 FBMS can be supported through the Fieldbus Extension Module (FEM100)
Control capabilities: Use a variety of control algorithms and various FBMS to provide control capabilities for a variety of process applications
Time synchronization: Support for time synchronization using optional external time from GPS satellites
Environmental adaptability: Rugged die-cast aluminum housing can work in harsh G3 environments
