Description
Parameters and Specifications:
Power Consumption: ≤5W
Technical Parameters: Industrial-grade design, IP30 rating, corrugated high-strength enclosure1
RJ45 Port: 10Base-T/100Base-TX auto-sensing, transmission distance <100 meters
Optical Port: 100Base-FX, SC/ST interface, supports single-mode (20/40/60/80Km selectable), multi-mode (2/5Km selectable), wavelength 1310nm
Power Supply: DC24V; Optional: AC/DC85-265V, DC-48V, DC12V
Protection: Built-in over-current protection, supports dual power input, supports dual power alarm information output (suitable for DC24V)
Dimensions and Weight:
Size (W×H×D): 50mm×136mm×118mm
Weight: Not specified but typically around 2KG
Features:
Ethernet Communication: Supports 10Base-T/100Base-TX and 100Base-FX
Protocol Support: Modbus TCP/IP, IPv6, IEEE 802.3az, and others
Redundancy: Supports O-Ring, MSTP (RSTP/STP), Open-Ring, O-Chain, and IEC 62439-2 MRP
Power over Ethernet (PoE): Supports IEEE 802.3at standard, providing up to 30W output per port
Clock Synchronization: Supports IEEE 1588v
