Description
Parameters and specifications:
Input channels: 32 independent channels.
Input range (per channel) : open circuit voltage 15-30V dc, short circuit voltage 0-5V dc.
Communication: Communicate with FCM and FCP through fieldbus.
Power requirements: 24 V dc +5%, -10%.
Power consumption (Max) : 3W (Max) 24V dc.
Heat dissipation (Max) : 5W (Max) at 24V dc.
Current: 4 mA (typical) at 5 to 60 V dc.
Features:
32 two-wire DC input channels, supporting 120V or 240V DC, 60V or 120V AC input.
Led indicators provide operational status display of fieldbus component functions.
Redundant fieldbus sockets, independent redundant DC sockets, and I/O cable sockets support redundant communication.
Complies with a number of electromagnetic compatibility (EMC) and safety standards, such as EN 50081-1, EN 50082-2, IEC 61000-4 series, etc.
Functions:
The FBM217 is mainly used in industrial automation systems as a controller module to receive and process signals from field equipment and pass them on to the master control station or other related equipment. It provides the interface to communicate with the field equipment, and realizes the data collection, processing and transmission, so as to support the operation and monitoring of the automatic system.
