Description
Parameters and specifications
Type: Communication redundant input interface module
Brand: FOXBORO
Origin: Probably from Switzerland or Pudong, Shanghai, China
Voltage: 24Vdc±5%
Current: In the range of 0-20.4mA per channel, but up to 33mA per channel
Accuracy: ±0.075% of the range
Input: 8 independently isolated channels supporting 4-20mA standard signals or HART devices
Communication: FCM is connected via component fieldbus and supports HART V6
Power requirements: Input voltage range 24Vdc±5%, consumption 7W (Max), heat dissipation 4W (Max)
Loop power supply protection: Each channel is completely isolated between channels, current limiting and voltage adjustment
Operating temperature: -20 to +70 degrees Celsius (-4 to +158 degrees Fahrenheit)
Size and weight
Dimensions: 10.4 cm x 4.5 cm x 11.4 cm
Weight: 0.284 kg (Shipping weight 1.5 kg)
series
The FBM216 belongs to a series under the FOXBORO brand, the name of which is not explicitly given in search results.
trait
Compact design: Strong pressed aluminum housing protects electronic circuits from physical damage
Environmental adaptability: The special design of the enclosure allows it to adapt to a variety of different environmental requirements, the highest environmental grade is ISA standard S71.04
Redundancy: A pair of FBM216 modules can provide a redundant fieldbus communication environment to ensure communication reliability
Isolated input: Each channel is completely isolated from other channels and ground, providing high security
effect
The FBM216 is mainly used in industrial automation systems as a communication redundant input interface module, which can connect and process signals from 4-20mA standard equipment and HART equipment, and communicate through the fieldbus to ensure accurate data transmission and stable operation of the system.
