Description
Parameters:
Input signal type: The FBM202 can accept various input signal types, such as analog signals, digital signals, etc.
Output signal type: The type of signal output by the device, which may vary by application.
Power requirements: The specific values of the power supply voltage and current required by the FBM202 are not directly given, but the power requirements of industrial automation equipment are usually detailed in the technical manual of the equipment.
Operating temperature range: The temperature range that the device can withstand under normal operating conditions, the specific value may vary by model and application.
Storage temperature range: Temperature range that the device can withstand when it is stored or not working. For details, see the technical manual.
Communication interfaces: The FBM202 supports communication interfaces, such as Ethernet. The specific communication protocols may vary depending on the model and application.
Control accuracy: The control accuracy or measurement accuracy of the FBM202 on the input signal may vary by model and application, but Foxboro products generally have high control accuracy and measurement accuracy.
Specifications:
Number of channels: The FBM202 typically has 8 channels for thermocouple/millivolt inputs.
Size and weight:
Size: The exact size may vary by vendor or application. For example, some vendors refer to a specification size of 200gmm, but this is not a standard representation of size and may refer to length or a specific dimension. There are also suppliers that mention the specification of 110, which may refer to another specification or size description.
Weight: The weight of the FBM202 may vary depending on the specific configuration and vendor. Some information mentions a weight of 1, but this may be an oversimplified representation, the specific weight should be referred to the technical manual or the data provided by the supplier.
Series:
The FBM202 is a product model in its own right, and it may belong to a specific Foxboro product family, but the specific family name is not mentioned in the given information.
Features:
Multi-channel isolation: The FBM202 has eight isolated thermocouple input channels and one isolated RTD reference temperature compensation channel.
Full range break indicator: Each thermocouple /MW channel provides full range break indicator characteristics.
High accuracy: For increased accuracy, the FBM202 includes SIGMA-DELTA data conversions in each channel.
Communication redundancy: The FBM202 supports redundant Ethernet fieldbus communication.
Modular design: The FBM202 has a modular design and can be easily inserted, removed and replaced.
Functions:
The FBM202 is mainly used in industrial automation systems to complete the signal conversion required for the interface between the electrical input signal from the field sensor and the fieldbus.
It executes an analog input application that provides configuration options for integration time and resolution limits for analog input signals.
