Description
Parameters and specifications:
Display size: 2.4 inches
Resolution: 240 x 320 pixels
Display color: 256 colors
Display brightness: 200 cd/m²
Display contrast ratio: 150:1
Touch screen type: resistive touch screen
Touch screen input: finger or stylus
CPU: 32-bit ARM Cortex-M3 processor
Memory: 4MB flash and 8MB RAM
Communication interface: RS-485 and RS-232 serial communication interface
Power input: 24V DC
Power consumption: 2W
Operating temperature: 0℃ ~ 50℃
Storage temperature: -20℃ ~ 60℃
Humidity range: 10% ~ 90% RH (non-condensing)
Seismic capacity: 10~55Hz, 0.75mm two-way 10min
Series:
EST0240 series
Features:
Touch screen function: Equipped with a touch screen, allowing users to operate and monitor through an intuitive interface.
Human Machine Interface (HMI) : Provides a user-friendly interface to facilitate interaction with industrial automation systems.
Display screens are used to visualize process data that engineers and operators need to understand, enabling real-time monitoring and control of production processes.
Servo motor control: This module may be used to control the servo motor for precise position control and motion control.
Multiple interface options: In addition to RS-485 and RS-232, there may be other communication interfaces, such as Ethernet, for communication and data exchange with other devices or systems.
Dustproof and waterproof design: to adapt to various challenges in industrial environments.
Functions:
Industrial Automation and Monitoring systems: EST0240Z05WBX00 is commonly used in industrial automation and monitoring systems to display and visualize various process data and information.
Production line monitoring: used to monitor the equipment status, production efficiency and product quality on the production line.
Equipment monitoring: Displays key performance parameters, fault information, and maintenance tips on industrial equipment.
Process industry: Used to monitor and control production processes in chemical, petrochemical, pharmaceutical and other industries.
Power industry: Displays critical grid information, generator status, and system operating parameters in power stations.
