Description
Parameters and Specifications:
- Monitoring Type: Shell Seismic Vibration Monitor12
- Application Range: Steam, Gas, Compressors, and Water Turbines12
- Measurement Range:
- Vrms (Metric): 5 – 100 mm/s (±25 to ±500 micrometers)
- Vrms (Inch): 0.197 inch/s to 3.937 inch/s (±0.984 mils to ±19.685 mils)2
- Frequency Range: 10 – 1000 Hz (VDI 2056, DIN 4566, ISO 3945), with optional ranges2
- Input Voltage Range: -5 – +15 VDC2
- Input Resistance: >100 kΩ2
- Sensor Compatibility: Works with electromechanical sensors 9266, 9267, or 9268
Series:
- Part of the CSI 6500 series of mechanical health monitors12.
Features:
- Dual-Channel: Provides monitoring for two independent channels2.
- Hot-Swappable: Modules conform to API 670 standards2.
- Configurable: Allows for remote selection of limit multipliers and trip bypasses2.
- Output Options: Includes buffered and scaled outputs, 0/4-20 mA output, and 0-10 V output12.
- Compatibility: Backward compatible with field-installed electromechanical sensors1
Applications:
- Used in critical rotating machinery, such as steam turbines, gas turbines, compressors, and water turbines12.
- Monitors the overall vibration of bearing housings in millimeter/second (inch/second) speed1.
- Part of a complete API 670 mechanical protection monitoring system when used with other CSI 6500 monitors
