EI813F

Description

‌Specifications and Functions‌:

The EI813F is an Ethernet module designed for use with the AC800F field controller.
It complies with the IEEE802.3 Ethernet standard and offers communication in line with the 10BaseT standard at a transmission rate of 10 MBit/s.
It features a 32-bit data bus and direct memory access to the main memory, with CPU overhead during runtime being less than 4%.
An optional battery is available to provide redundant battery backup for the main memory‌1.

‌Weight and Dimensions‌:

Specific weight and dimension details for the EI813F are not provided in the sources consulted. However, as an industrial Ethernet module, it is likely to be compact and designed for installation within industrial control systems.

‌Features‌:

The EI813F incorporates two integrated LED indicators on the front panel to display the current communication status.
It supports system bus communication via Ethernet, enabling high-speed data transfer between the CPU and devices connected to the system bus.
The module has its dedicated communication processing chip and corresponding firmware, which supports upgrades via the system bus‌2.

‌Application Areas‌:

The EI813F is primarily used in industrial automation systems, serving as a critical component of control systems for data communication and information transmission.
It can be paired with controllers such as PLCs or DCSs to enable remote monitoring and fault diagnosis of industrial equipment and processes‌1.

‌Additional Notes‌:

The EI813F is part of ABB’s product line and is known for its reliability and performance in industrial settings.
While exact weight and dimension details are unavailable, the module is designed for ease of installation and integration within industrial control systems.
