Description
argument
Input voltage: 9-32 VDC (24VDC, 48VDC are also mentioned)
Operating temperature: -40℃ to +85℃
Output: Up to 12.5A
Frequency range: 50/60 Hz
Protection level: IP 54
specification
Product Series: EGCP-2
Scope of application: Mainly used for voltage and frequency automatic regulation of the generator set, to achieve the automatic operation of diesel or gas engine generator set, protection and management
Maximum designed application unit power: 30.000kW
Size and weight
Size:
Dimensions: 282mm H x 358mm W x 69mm D (operation control panel)
Product size: 100mm x 50mm x 20mm (controller itself)
Weight:
Product weight: 1.2kg (controller itself)
Digital control panel weight: 2.9kg (may refer to the entire control panel system)
trait
Microprocessor control: Integrated engine-generator management device based on microprocessor control
Flexible configuration: It can be flexibly configured to adapt to different working environments, including isolated standby power stations or grid-connected control scenarios
Multiple functions: including engine control, generator set synchronization, automatic sequencing of multiple units, automatic start/stop control, digital display of engine and generator data, actual power load control, reactive power control, generator set protection, Modbus communication, etc
