DSSR122

Description

argument
Rated current: 122A
Rated voltage: 400V AC
Starting current: 0% to 200% adjustable
Start time: 0.5s to 60s adjustable
Stop time: 0.5s to 60s adjustable
Control mode: internal control, external control
Communication interface: RS485
Communication rate: 9600bps (possible, depending on configuration)
specification
Series: ABB Ability™ Softstarters series
Type: Digital soft starter
Shell type: IP20
Installation mode: wall hanging
Size and weight
Net depth/length: 238.5mm
Product height: 72mm
Product net width: 162mm
Product net weight: 2.35kg (for some models, such as DSSR122 4899001-NK)

trait
Smooth start and stop: Provides a smooth start and stop process, avoids current surges and mechanical shocks, and protects the motor and equipment
Multiple start modes: Supports multiple start modes, such as ramp start, current limiting start, soft pulse start, etc., to meet different application requirements
Reliable performance: The use of mature technology and high-quality components, with reliable performance and long service life
Easy to use: provides intuitive interface and simple operation, easy to use
Communication interface: Supports communication interfaces such as RS485, which facilitates communication and data exchange with other devices and systems
effect
Control AC motor: DSSR122 digital soft starter is mainly used to control the start and stop process of AC motor, through smooth start and stop to reduce the current surge and mechanical shock, so as to protect the motor and equipment.
Protect the motor and equipment: By precisely controlling the motor start and stop process, avoid overcurrent and mechanical shock damage to the motor and equipment, extend the service life of the equipment.
Improve system efficiency: By optimizing the motor start and stop process, reduce energy waste and improve the overall efficiency of the system.
