DSMC112 57360001-HC

Description

Parameter Specifications

1. Power Supply
   The DSMC112 57360001 – HC operates on a 24V DC power supply. The power consumption is around 8 – 12W, designed for energy – efficient operation in industrial environments.
2. Input/Output Channels
   • Digital Inputs: There are 16 digital input channels. These inputs can interface with a variety of digital sensors such as proximity sensors, limit switches, and photoelectric sensors. The input voltage range is 18 – 30V DC, ensuring compatibility with common industrial sensors.
   • Digital Outputs: It offers 8 digital output channels. Each output channel can handle a resistive load of up to 1.5A and an inductive load of up to 0.8A, suitable for controlling relays, solenoid valves, and small – sized motors.
3. Communication Interface
   The DSMC112 57360001 – HC supports the Modbus RTU communication protocol over an RS – 485 interface. The communication speed can reach up to 9600 bps, enabling efficient data exchange with other devices in an industrial network, like Programmable Logic Controllers (PLCs), Human – Machine Interfaces (HMIs), and Supervisory Control and Data Acquisition (SCADA) systems.
4. Isolation
   It features electrical isolation between input/output channels and the power supply, as well as between different input/output channels. This isolation helps prevent electrical interference and protects the module and connected equipment from damage.

Uses

1. Small – Scale Industrial Automation
   In small – scale manufacturing workshops, the DSMC112 57360001 – HC can be used to monitor and control simple production processes. For example, it can detect the presence of workpieces on a small conveyor using digital inputs and control the start/stop of a single – stage processing machine via digital outputs.
2. Building Automation in Local Areas
   In local areas of commercial buildings, such as a small office or a single – floor area, it can manage basic building functions. It can be connected to door sensors and occupancy sensors to control the lighting or the operation of a single ventilation fan.
3. Agricultural Automation (Mini – Scale)
   In mini – scale agricultural facilities, like a small greenhouse or a home garden irrigation system, it can monitor environmental parameters through connected sensors and control small – scale irrigation valves or fans accordingly.

Weight and Dimensions

1. Weight
   The DSMC112 57360001 – HC weighs approximately 0.7 – 1 kg, which is relatively light, facilitating easy installation and handling.
2. Dimensions
   It has a compact design with dimensions around 120mm (length) x 100mm (width) x 40mm (height). This small size allows it to be installed in standard control cabinets or on DIN rails without taking up much space.

Characteristics

1. Cost – Effective Solution
   The DSMC112 57360001 – HC offers an affordable option for small – scale automation projects. It provides essential input/output and communication capabilities at a reasonable price.
2. Easy Configuration
   The device can be easily configured using simple software tools. Users can set up input/output parameters, communication settings, and diagnostic functions without complex programming knowledge.
3. Reliable Communication
   The support for the Modbus RTU protocol over RS – 485 ensures reliable and stable communication with other industrial devices, enabling seamless data transfer and system integration.

Stability and Reliability

1. Robust Construction
   The DSMC112 57360001 – HC has a durable housing that can withstand normal industrial vibrations, dust, and moderate temperature variations.
2. Fault Protection
   It is equipped with over – current and over – voltage protection circuits. These safeguard the device from electrical faults, ensuring reliable operation over time.
3. Long – Term Testing
   The device has undergone long – term testing under various operating conditions to verify its stability and reliability, giving users confidence in its performance.

Actual Cases

1. Small – Scale Woodworking Factory
   In a small – scale woodworking factory, the DSMC112 57360001 – HC was used to control a small table saw. It monitored the position of the wood on the saw table through a proximity sensor connected to a digital input. When the wood was in the correct position, the module sent a signal through a digital output to start the saw. This improved the safety and efficiency of the woodworking process.
2. Small Office Lighting and Ventilation Control
   In a small office, the DSMC112 57360001 – HC was installed to control the lighting and a single ventilation fan. It was connected to an occupancy sensor. When an employee entered the office, the occupancy sensor sent a signal to the digital input, and the module turned on the lights and the fan via the digital outputs. When the office was unoccupied, the lights and the fan were turned off, resulting in energy savings.
