DS200UPSAG1AFD

Description

DS200UPSAG1AFD

1. Technical Specifications

• Power Supply:
  • The DS200UPSAG1AFD typically operates on a dual – input power system. It can accept both 125V DC and 250V DC inputs, providing flexibility in different industrial power environments. The standby power consumption is low, around 5 – 10W, while the full – load power consumption depends on the connected load.
• Input/Output Configuration:
  • Digital Inputs: It is equipped with 16 digital inputs. These inputs are designed to receive signals from various digital sensors, such as proximity sensors, pressure switches, and level sensors. They can handle input voltages in the range of 5 – 24V DC.
  • Digital Outputs: There are 8 digital outputs. Each output can drive a load with a maximum current of 1A, suitable for controlling small relays, indicator lights, and solenoids.
  • Analog Inputs: There are 4 analog inputs. They can accept signals in the ranges of 0 – 10V or 4 – 20mA, with a 12 – bit resolution, enabling accurate measurement of analog quantities like temperature, pressure, and flow.
  • Analog Outputs: 2 analog outputs are available, capable of outputting signals in the same ranges as the analog inputs, for precise control of analog – based devices.
• Processing Speed:
  • The response time for digital input changes is less than 10ms, and for analog input changes, it is approximately 15ms. This allows for relatively quick response to system changes.
• Communication Interfaces:
  • It supports an RS – 485 serial communication interface with Modbus RTU protocol, which is commonly used in industrial automation for data exchange with other devices and control systems.

2. Applications

• Industrial Automation:
  • In manufacturing industries, it can be used to control and monitor production processes. For example, it can manage the operation of conveyor belts, control the start and stop of machines, and monitor the status of production equipment.
• Power Generation and Distribution:
  • In power plants and substations, it can monitor power – related parameters such as voltage, current, and frequency. It can also control the switching of electrical circuits and the operation of backup power supplies.
• Environmental Monitoring:
  • In environmental monitoring systems, it can measure and record parameters like temperature, humidity, and air quality. It can then send the data to a central control system for analysis.

3. Weight and Dimensions

• Weight:
  • The module weighs about 0.9 kg, making it relatively lightweight and easy to install and handle.
• Dimensions:
  • The overall dimensions are: length – 150mm, width – 120mm, height – 50mm. Its compact size allows for installation in standard electrical cabinets or control panels.

DS200UPSAG1AFD

DS200UPSAG1AFD

4. Features

• Dual – Input Power:
  • The ability to accept both 125V DC and 250V DC inputs provides redundancy and adaptability in different power supply scenarios.
• Flexible Input/Output Configuration:
  • With a combination of digital and analog inputs and outputs, it can be used in a wide variety of applications, allowing for customized control and monitoring solutions.
• Modbus Communication:
  • The support for Modbus RTU protocol on the RS – 485 interface enables easy integration with other Modbus – compatible devices and control systems, facilitating data sharing and system expansion.

5. Stability and Reliability

• Robust Design:
  • The module is housed in a durable enclosure that offers protection against dust, moisture, and mechanical vibrations. This ensures stable operation in harsh industrial environments.
• Fault – Tolerant Features:
  • It is designed with built – in protection mechanisms such as over – current protection, short – circuit protection, and over – voltage protection. These features safeguard the module from electrical faults and extend its service life.
• Quality Components:
  • The use of high – quality electronic components and strict quality control during manufacturing ensure long – term reliability and consistent performance.

6. Real – world Examples

• Food Processing Plant:
  • In a food processing plant, the DS200UPSAG1AFD can control the temperature and humidity in storage areas. It monitors the environmental parameters through analog sensors and controls the operation of HVAC systems via digital outputs to maintain optimal storage conditions for food products.
• Small – scale Power Station:
  • In a small – scale power station, it can monitor the output voltage and current of generators. If there are any abnormal changes in the electrical parameters, it can send signals to control the generator’s operation or switch to backup power sources to ensure continuous power supply.
