DS200TBQBG1ACB

Description

Parameters and specifications:

Model: DS200TBQBG1ACB is an LST TMR reheat card manufactured and designed by GE for the Mark V series of steam turbine control systems.
Frequency: 13.560MHz.
Transmission power: 500w.
Reflected power (at power) : <3w. Load current: 10ARMS. Load voltage: 4000VRMS. Transmission efficiency: >90%.
Load impedance: 50Ω.

Size and weight:

Size: There are two versions, one is 430mm(D)x220mm(W)x130mm(H), the other is 20.4×22.2×3.7cm. This may be due to differences in product versions or different measurement methods.
Weight: 5kg.

DS200TBQBG1ACB

Features:

Installation and connection: It has the characteristics of convenient installation, and supports a variety of programming languages and development environments, which is easy for users to configure and program.
Function and application: Suitable for chemical industry, paper making, power generation, oil, natural gas and other fields. At the same time, it is part of the protection core and the main trip circuit, including at least two sets of main trip relays and three sets of emergency trip relays, which are used to ensure the stable operation of the system and the safe trip in case of failure.
