DS200SIOBH1ABA

Description

Parameter Specifications

1. Power Supply
   The DS200SIOBH1ABA typically requires a 24V DC power supply. It has a relatively low power consumption, around 7 – 10W, which helps in reducing energy costs during continuous operation in industrial environments.
2. Input/Output Channels
   • Digital Inputs: There are 16 digital input channels. These inputs are designed to accept signals from various digital sensors. The input voltage range is 18 – 30V DC, enabling it to interface with sensors such as proximity sensors, limit switches, and photoelectric sensors commonly used in industrial settings.
   • Digital Outputs: It offers 8 digital output channels. Each output channel can handle a resistive load of up to 2A and an inductive load of up to 1A. This allows it to control a variety of devices, including relays, solenoid valves, and small – scale motors.
3. Communication Interface
   The module supports the Modbus RTU communication protocol over an RS – 485 interface. With a communication speed of up to 115.2 kbps, it can effectively communicate with other devices in an industrial network, such as PLCs, HMIs, and SCADA systems.

Uses

1. Industrial Automation
   • In manufacturing plants, the DS200SIOBH1ABA can monitor and control production lines. For example, it can detect the presence of workpieces on a conveyor using digital inputs and control the movement of robotic arms or the start/stop of processing machines through digital outputs.
2. Building Automation
   • In commercial buildings, it can manage building systems like lighting, ventilation, and access control. By connecting to occupancy sensors and door sensors, it can automatically adjust these systems based on the building’s usage.
3. Power Systems Monitoring
   • In power generation and distribution facilities, it can monitor the status of electrical switches and breakers via digital inputs. It can then send control signals through digital outputs to ensure the safe and efficient operation of the power system.

Weight and Dimensions

1. Weight
   The DS200SIOBH1ABA weighs approximately 1.4 – 1.7 kg, which is relatively light. This makes it easy to handle and install, especially in confined spaces within control cabinets.
2. Dimensions
   It has a compact design with dimensions around 170mm (length) x 130mm (width) x 60mm (height). This small form – factor allows it to be installed on standard DIN rails or in control cabinets without taking up excessive space.

Characteristics

1. High – Density I/O
   The combination of 16 digital inputs and 8 digital outputs in a single module provides a high – density I/O solution. This reduces the need for multiple modules, saving both space and cost in system integration.
2. Ease of Configuration
   The module can be easily configured using simple software tools. Users can set up input/output parameters, communication settings, and diagnostic functions without requiring extensive programming knowledge.
3. Electrical Isolation
   It features electrical isolation between input/output channels and the power supply. This isolation helps protect the module and connected devices from electrical interference and potential damage.

Stability and Reliability

1. Robust Construction
   The DS200SIOBH1ABA has a durable housing that can withstand harsh industrial environments, including dust, vibration, and temperature variations within a specified range.
2. Fault Protection
   It is equipped with over – current, over – voltage, and short – circuit protection circuits. These safeguard the module from electrical faults, ensuring reliable long – term operation.
3. Long – Term Testing
   The module has undergone extensive long – term testing under various operating conditions to verify its stability and reliability over its service life.

Actual Cases

1. Automotive Assembly Line
   In an automotive assembly plant, the DS200SIOBH1ABA was used to control a part – feeding conveyor. It received signals from sensors detecting the presence of car parts on the conveyor through digital inputs. Based on these signals, it controlled the conveyor’s speed and direction via digital outputs, ensuring a smooth and efficient assembly process.
2. Hotel HVAC System
   In a hotel, the module was installed to manage the HVAC system. It was connected to temperature and occupancy sensors. Using digital inputs to gather data, it adjusted the operation of air – conditioning units through digital outputs, maintaining a comfortable environment for guests while optimizing energy consumption.
