Description
Specifications and parameters
voltage : 24V
resistance series : five strings, each string of three connector, a total of 15 input points
jumpers : Each string contains two optional jumpers to adjust the output signal
Certified : in compliance with CSA, EC and UL standards
Dimensions and weight
Dimensions : 8.8 x 3.6 x 4.7 inches (overall dimensions)
Weight : 2KG
core role
voltage feedback : attenuates the AC and DC voltages on the SCR bridge to ensure accurate derived bridge voltage feedback
Detailed features
output connection : five string outputs connected to a 20-pin strip connector
protection mechanism : built-in metal oxide varistor (MOV), to prevent the output voltage is too high
load resistance : The required load resistance is located on the connected grid distribution status board, not on the NATO board
attenuator Settings : Attenuator voltage is set by spike connector and jumper to suit a variety of input requirements
Application field
Suitable for industrial automation and control systems requiring precise voltage feedback control, such as power, energy, manufacturing and other fields
DS200NATOG2A, as a voltage feedback scale board produced by GE General Electric, plays an important role in industrial automation and control systems with its precise control and stable performance
