Description
Parameters and specifications:
Wavelength range: 190~1100 nm.
Wavelength accuracy: ±1nm (within 200nm~900nm band).
Wavelength resolution: 0.1nm.
Bandwidth: 2nm.
Photometric range: ±3 ABS.
Stray light: 220nm > 3.3ABS.
Reading mode: A reading mode with transmittance, absorbance, and concentration.
Communication interface: includes USB1.1, USB interface, and interface for connecting computers, printers, and external keyboards.
Power supply: 200~240V, 50/60 Hz.
Size and weight:
Weight: 15.5kg.
DS200DDTBG2ABB
DS200DDTBG2ABB
DS200DDTBG2ABB
Features:
Function: Acts as an LCI auxiliary I/O terminal board to create system connections for auxiliary I/O signals. Obtain power from the DS200ADMA board and connect to it.
Input/Output: Built-in multiple inputs and outputs, including high-voltage AC input, high-current signal input, low-current signal input, 4-20 mA current loop input, and non-dedicated voltage input. There are also four buffered analog outputs and two 4-20mA current outputs. In addition, there are 16 digital inputs/outputs.
Test points: 33 built-in TP test points for signal measurement.
LED indication: Includes 17 leds (DS1-DS17) for status indication.
