Description
Parameters and specifications
Purpose: Used to provide control level power supply for drivers and cabinet fans.
Operating voltage: The input voltage range may include 85~264VAC and the output voltage is 24VDC.
Output power: 360W.
Maximum output current: 15A.
Operating temperature range: -25~70℃.
Size and weight
Dimensions: Approx. 115mm x 48mm x 150mm
Weight: About 1.2kg
trait
Integrated circuits and components: including voltage and current feedback circuits, motor voltage attenuation circuits, AC line magnetism and zero crossing circuits, contactor drive circuits, field/armature SCR ignition circuits, etc.
Indicators and jumpers: There are neon indicators to indicate blown fuses in 115 VAC lines, and two LED indicators to indicate blown fuses in +24 VDC and -24 VDC lines. There are also 12 configurable jumpers and seven 4-bit DIP switches.
Protection function: with over voltage, under voltage, over current and short circuit protection functions.
Communication interface: Supports RS485, CAN port, and is compatible with MODBUS protocol and CANOPEN protocol.
Flexible configuration: Provides two high-speed pulse input ports, two analog input ports, six DI input ports, and four DO output ports.
