Description
Parameters and specifications:
High speed: under 3000 steps, the basic instruction is 0.08μs/ step; For more than 3001 steps, the basic instruction is 0.58μs/ step.
Pulse output: up to 50KHz×2CH.
High speed counting: up to 50KHz×4CH.
I/O points: Maximum 216 points.
Built-in features: Built-in 2CH analog input (voltage, potentiometer, thermistor input optional) and calendar clock.
Serial interface: Commonly used for programming, parameterization, and diagnostics during startup operations and services, and can be operated as RS-232 or RS-485.
Program capacity: L14R/L30R is 2.5K steps; L40R/L60R/L40MR/L60MR is an 8K step.
Features:
Multi-function: relay + transistor hybrid output, can respond to a variety of needs.
Scalability: One control unit can continuously expand the expansion units of 3 FPX, and can also be further expanded by using the FP0 expansion unit.
High cost performance: under the premise of meeting customer needs, reduce costs for customers to the maximum extent.
Functions:
is a controller used to control the servo motor, its role is similar to the frequency converter acting on the ordinary AC motor, is a part of the servo system.
It generally controls the servo motor through three ways of position, speed and torque to achieve high-precision positioning of the transmission system.
